Table 80: Sleep Function Settings
Index Parameter
P3.12.4.1 SP1 Sleep Frequency
P3.12.4.2 SP1 Sleep Delay
P3.12.4.3 SP1 Wake-up Level
SP2 Sleep Frequency
P3.12.4.4
SP2 Sleep Delay
P3.12.4.5
SP2 Wake-up Level
P3.12.4.6

4.5.13 Group 3.13: Motor Preheat Parameters

Table 81: Motor Preheat Parameters
Index Parameter
P3.13.1 Motor Preheat Func-
tion
P3.13.2 Preheat Temperature
Limit
P3.13.3 Motor Preheat Cur-
rent
P3.13.4 Motor Preheat ON
P3.13.5 Preheat Motor Tem-
perature

4.5.14 Group 3.14: Mechanical Brake

Table 82: Mechanical Brake Parameters
Index Parameter
P3.14.1 Brake Control
P3.14.2 Brake Mechanical Delay
Danfoss A/S © 2021.09
Min Max
0.00 320.00
0 300
0.00 320.00
0 3000
Min Max Unit Default
0 4 0
-20 100 °C 0
0 31048 A 0
Varies Varies DigIN
Slot0.1
0 3 0
Min Max Unit
0 2
0.00 60.00 s
Unit Default
Hz 0.00
s 0
% 0.0000
Hz 0.00
s 0
% 0.0000
ID Description
1225 0 = Not used
1 = Always in stop state
2 = Controlled by DI
3 = Temperature limit
4 = Temperature limit (Measured motor temper-
ature)
1226
1227
1044 OPEN = No action
CLOSED = Preheat activated in Stop state
1045
0 = Not used
1 = Temperature Input 1
2 = Temperature Input 2
3 = Temperature Input 3
Default ID Description
0 1541 0 = Disabled
1 = Enabled
2 = Enabled with brake status super-
vision
0.00 1544
AB319735759636en-000101 / DPD01822 | 75
INU Application
ID Description
1016
1017
1018
1075 See P3.12.4.1.
1076 See P3.12.4.2.
1077 See P3.12.4.3.
