5.5.8 Group 3.8: Protections

Table 166: General protection settings
Index Parameter
P3.8.1.2 Response to External Fault
P3.8.1.3 Undervoltage Fault
P3.8.1.4 Response to Output Phase
Fault
P3.8.1.5 Response to Fieldbus Com-
munication Fault
P3.8.1.6 Slot Communication Fault
P3.8.1.7 Thermistor Fault
P3.8.1.8 Earth Fault
P3.8.1.9 Preset Alarm Frequency
P3.8.1.10 HS Cap Vrms Enable
P3.8.1.11 Enclosure Humidity and Tem-
perature
P3.8.1.12 Input phase fault ripple limit
P3.8.1.13 Current imbalance - belt
P3.8.1.14 Neutral to ground fault re-
sponse
P3.8.1.15 Redundant switchover indi-
cation
122 | Danfoss A/S © 2021.09
Min Max Unit Default
0 3 2
0 1 0
0 3 2
0 5 3
0 3 2
0 3 0
0 3 3
P3.3.1.1 P3.3.1.2 Hz 25.00
0
0 3 1
V 150.0
0 2 2
0 1 1
0 2 1
ID Description
701 0 = No action
1 = Alarm
2 = Fault (Stop according to stop func-
tion)
3 = Fault (Stop by coasting)
727 0 = Fault stored in history
1 = Fault not stored in history
702 See P3.8.1.2.
733 0 = No action
1 = Alarm
2 = Alarm + preset fault frequency
(P3.8.1.10)
3 = Fault (Stop according to stop func-
tion)
4 = Fault (Stop by coasting)
734 See P3.8.1.2.
732 See P3.8.1.2.
703 See P3.8.1.2.
183
3304
3360
0 = No action
1 = Alarm
2 = Fault (Stop according to stop func-
tion)
3 = Fault (Stop by coasting)
4007
4039
0 = No action
1 = Alarm
2 = Fault, coast
4040
0 = No action
1 = Fault, coast
750
0 = No action
1 = Alarm
2 = Alarm + Autoreset
