6 Parameters Menu

6.1 Group 3.1: Motor Settings

Table 28: Motor Nameplate Parameters
Index
Parameter
P3.1.1.1 Motor Nominal Voltage
P3.1.1.2 Motor Nominal Frequency
P3.1.1.3 Motor Nominal Speed
P3.1.1.4 Motor Nominal Current
P3.1.1.5 Motor Cos Phi (Power Factor)
P3.1.1.6 Motor Nominal Power
Table 29: Motor Control Settings
Index Parameter
P3.1.2.2 Motor Type
P3.1.2.3 Switching Frequency
P3.1.2.4 Identification
P3.1.2.5 Magnetizing Current
P3.1.2.6 Motor Switch
P3.1.2.10 Overvoltage Control
P3.1.2.11 Undervoltage Control
P3.1.2.12 Energy Optimization
P3.1.2.13 Stator Voltage Adjust
P3.1.2.15 Rs Voltage Drop
P3.1.2.16 Ls Voltage Drop
P3.1.2.17 Motor BEM Voltage
88 | Danfoss A/S © 2023.08
Min Max
Varies Varies
8.00 320.00
24 19200
IH * 0.1 IH * 2
0.30 1.00
Varies Varies
Min Max Unit
0 2
1.5 Varies kHz
0 2
0.0 2*IH A
0 1
0 1
0 1
0 1
50.0 150.0 %
0.00 50.00 %
0.00 200.00 %
0 Varies V
Unit Default ID
V Varies 110
Hz 50 / 60 111
rpm Varies 112
A Varies 113
Varies 120
kW Varies 116
Default ID Description
0 650 0 = Induction motor
1 = PM motor
2 = Reluctance motor
Varies 601
0 631 0 = No action
1 = At standstill
2 = With rotation
0.0 612
0 653 0 = Disabled
1 = Enabled
1 607 0 = Disabled
1 = Enabled
1 608 0 = Disabled
1 = Enabled
0 666 0 = Disabled
1 = Enabled
100.0 659
0.00 662
0.00 673
0 674
