VACON® 3000
Application Guide
Index Parameter
P3.5.3.6.2 RO2 Function
P3.5.3.6.3 RO3 Function
Shows only the parameters for the outputs on option boards in slots C, D, and E. Make the selections as in Basic AO1 Function
(P3.5.4.1.1). This group or these parameters are not visible if there are no digital outputs in slots C, D, or E.
Table 58: Analog Output Settings on Standard I/O board
Index Parameter
P3.5.4.1.1 AO1 function
P3.5.4.1.2 AO1 filter time
P3.5.4.1.3 AO1 minimum signal
P3.5.4.1.4 AO1 minimum scale
P3.5.4.1.5 AO1 maximum scale
Danfoss A/S © 2021.09
Min Max Unit Default
0 21 0
0 21 0
N O T I C E
Min Max Unit Default
2
0 31
1.00
0.0 300.0 s
0
0 1
0.00
Hz
0.00
Hz
ID Description
15 = Precharge permissive
16 = GSW unlock
17 = Run cooling
18 = Close breaker
19 = STO active
20 = Pulse close breaker
21 = Pulse open breaker
6041 See ID 6040.
6042 See ID 6040.
ID Description
10050 0 = TEST 0%
1 = TEST 100%
2 = Output freq (0 - fmax)
3 = Freq reference (0 - fmax)
4 = Motor speed (0 - Motor nominal speed)
5 = Output current (0 - InMotor)
6 = Motor torque (0 - TnMotor)
7 = Motor power (0 - PnMotor)
8 = Motor voltage (0 - UnMotor)
9 = DC-link voltage (0 - 1000V)
10 = PID Setpoint (0-100%)
11 = PID Feedback (0-100%)
12 = PID output (0-100%)
13 = ProcessDataIn1 (0-100%)
14 = ProcessDataIn2 (0-100%)
15 = ProcessDataIn3 (0-100%)
16 = ProcessDataIn4 (0-100%)
17 = ProcessDataIn5 (0-100%)
18 = ProcessDataIn6 (0-100%)
19 = ProcessDataIn7 (0-100%)
20 = ProcessDataIn8 (0-100%)
10051 0 = No filtering
10052 0 = 0 mA / 0 V
1 = 4 mA / 2 V
10053
10054
AB319735759636en-000101 / DPD01822 | 63
INU Application
