VACON® 3000
Application Guide
A
[Hz]
B
C
0%
0 mA
Illustration 20: The analog input signal range, selection 0
A
Frequency reference
B
Max freq reference
A
[Hz]
B
C
0%
20%
0 mA
4 mA
Illustration 21: The analog input signal range, selection 1
A
Frequency reference
B
Max freq reference
7.53 (ID 380) AI1 Custom. MIN
Location in the menu:
•
INU application: P3.5.2.1.4
•
AFE application: P3.5.2.1.4
•
BCU application: P3.4.2.1.4
Use this parameter to adjust the range of the analog input signal between -160% and 160%.
7.54 (ID 381) AI1 Custom. MAX
Location in the menu:
172 | Danfoss A/S © 2021.09
50%
100%
10 mA
20 mA
50%
100%
10 mA
20 mA
D
[%]
C
Min freq reference
D
Analog input signal
D
[%]
C
Min freq reference
D
Analog input signal
Parameter descriptions
AB319735759636en-000101 / DPD01822
