VACON® 3000
Application Guide
•
INU application: P3.5.3.2.5
•
AFE application: P3.5.3.2.5
•
BCU application: P3.4.3.2.5
Use this parameter to set the ON delay for the relay output.
7.588 (ID 11006) RO2 OFF Delay
Location in the menu:
•
INU application: P3.5.3.2.6
•
AFE application: P3.5.3.2.6
•
BCU application: P3.4.3.2.6
Use this parameter to set the OFF delay for the relay output.
7.589 (ID 11007) RO3 Function
Location in the menu:
•
INU application: P3.5.3.2.7
•
AFE application: P3.5.3.2.7
•
BCU application: P3.4.3.2.7
Use this parameter to select a function or a signal that is connected to the relay output. The parameter is not visible if only 2 output
relays are installed. See
7.583 (ID 11001) RO1
7.590 (ID 11008) RO3 ON Delay
Location in the menu: P3.5.3.2.8
Use this parameter to set the ON delay for the relay output. The parameter is not visible if only 2 output relays are installed.
7.591 (ID 11009) RO3 OFF Delay
Location in the menu: P3.5.3.2.9
Use this parameter to set the OFF delay for the relay output. The parameter is not visible if only 2 output relays are installed.
7.592 (ID 15523) User Defined Fault 1
•
Location in the menu: P3.5.1.32 (In I/O Configuration parameter menu)
•
Location in the menu: P3.9.9.1 (In Protections parameter menu)
Use this parameter to set the digital input signal that activates User Defined Fault 1 (Fault ID 1114).
7.593 (ID 15524) User Defined Fault 2
•
Location in the menu: P3.5.1.33 (In I/O Configuration parameter menu)
•
Location in the menu: P3.9.10.1 (In Protections parameter menu)
Use this parameter to set the digital input signal that activates User Defined Fault 2 (Fault ID 1115).
7.594 (ID 15525) Response to User Defined Fault 1
Location in the menu: P3.9.9.2
Use this parameter to select the response of the drive to User Defined Fault 1 (Fault ID 1114).
7.595 (ID 15526) Response to User Defined Fault 2
Location in the menu: P3.9.10.2
Use this parameter to select the response of the drive to User Defined Fault 2 (Fault ID 1115).
7.596 (ID 15647) Frequency Filter Time Constant
Location in the menu: P3.1.5.10
Use this parameter to set the filter time constant for the shaft frequency estimate in sensorless control.
268 | Danfoss A/S © 2021.09
Function.
Parameter descriptions
AB319735759636en-000101 / DPD01822
