V5.1.12 Analogue Output 1
V5.1.13 Relay Output 1
V5.1.14 Relay Output 2
V5.1.15 Relay Output 3
5.7.2 Option Board Slots
The parameters in this menu are different for all the option boards. The parameters of the installed option board is shown. If there is
no option board in the slots C, D or E, no parameters are shown. See more about the location of the slots in chapter
Information on the Programming.
When an option board is removed, the fault code 39 and the fault name Device removed show on the display.
Table 178: Option Board Related Parameters
Menu Function
Slot C Settings
Monitoring
Slot D Settings
Monitoring
Slot E Settings
Monitoring

5.7.3 Real Time Clock

Table 179: The Real Time Clock Parameters in the I/O and Hardware Menu
Index Parameter Min
V5.5.1 Battery State 1
P5.5.2 Time
P5.5.3 Date
P5.5.4 Year
P5.5.5 Daylight Sav- 1
ing
P5.5.6 Time Offset
128 | Danfoss A/S © 2021.09
Min Max Unit Default
0 100 % 0.00
0 1 0
0 1 0
0 1 0
Description
The settings that are related to the option board.
Monitor the data that is related to the option board.
The settings that are related to the option board.
Monitor the data that is related to the option board.
The settings that are related to the option board.
Monitor the data that is related to the option board.
Max Unit De-
fault
3
hh:mm:ss
dd.mm.
yyyy
4
ID Description
2513 Status of the analog output signal
2514 Status of the relay output signal
2515 Status of the relay output signal
2516 Status of the relay output signal
ID Description
2205
Status of the battery.
1 = Not installed
2 = Installed
3 = Replace the battery
2201 The current time of the day
2202 The current date
2203 The current year
2204
The daylight saving rule
1 = Off
2 = EU: starts on the last Sunday in March, ends on the last
Sunday in October
3 = US: starts on the 2nd Sunday in March, ends on the 1st
Sunday in November
4 = Russia (permanent)
2614
AFE Application
3.1 General
