VACON® 3000
Application Guide
Index Parameter
P3.6.28 Fieldbus Data In 12 Selection
P3.6.29 Fieldbus Data In 13 Selection
P3.6.30 Fieldbus Data In 14 Selection
P3.6.31 Fieldbus Data In 15 Selection
P3.6.32 Fieldbus Data In 16 Selection
P3.6.33 Fieldbus profile
Table 60: The default values for Process Data Out in fieldbus
Data
Process Data Out 1
Process Data Out 2
Process Data Out 3
Process Data Out 4
Process Data Out 5
Process Data Out 6
Process Data Out 7
Process Data Out 8
Example
The value 2500 for Output frequency equals 25.00 Hz, because the scale is 0.01. All the monitoring values that you can find in the
Monitor menu are given the scale value.

4.5.7 Group 3.7: Prohibit Frequencies

Table 61: Prohibit Frequencies Parameters
Index Parameter
P3.7.1 Prohibit Frequency Range 1 Low Limit
P3.7.2 Prohibit Frequency Range 1 High Limit
P3.7.3 Prohibit Frequency Range 2 Low Limit
P3.7.4 Prohibit Frequency Range 2 High Limit
P3.7.5 Prohibit Frequency Range 3 Low Limit
P3.7.6 Prohibit Frequency Range 3 High Limit
P3.7.7 Ramp Time Factor
Danfoss A/S © 2021.09
Min Max Unit
1 2
Default Value
Output frequency
Motor speed
Motor current
Motor torque
Motor power
Motor voltage
DC link voltage
Last active fault code
Min Max
-1.00 320.00
0.00 320.00
0.00 320.00
0.00 320.00
0.00 320.00
0.00 320.00
0.1 10.0
Default ID
0 6411
0 6412
0 6413
0 6414
0 6415
1 6417
Scale
0.01 Hz
1 rpm
0.1 A
0.1%
0.1%
0.1 V
1 V
1
Unit Default ID
Hz 0.00 509
Hz 0.00 510
Hz 0.00 511
Hz 0.00 512
Hz 0.00 513
Hz 0.00 514
Times 1.0 518
AB319735759636en-000101 / DPD01822 | 65
INU Application
Description
1 = Standard
2 = Bypass
Description
0 = Not used
0 = Not used
0 = Not used
0 = Not used
0 = Not used
0 = Not used
