VACON® 3000
Application Guide
Index
Parameter
1.8
Motor Nominal Frequency
1.9
Motor Nominal Speed
1.10
Motor Nominal Current
1.11
Motor Cos Phi (Power Fac-
tor)
1.12
Identification
1.13
Start Function
1.14
Stop Function
1.15
Automatic Reset
1.16
Response to External Fault
1.17
Response to AI Low Fault
1.18
Remote Control Place
1.19
I/O Control Reference A
Selection
1.20
Keypad Control Reference
Selection
1.21
Fieldbus Control Refer-
ence Selection
34 | Danfoss A/S © 2021.09
Min
Max
Unit
Default
8.00
320.00
Hz
0.00
24
19200
RPM
0
34
680
A
0
0.30
1.00
0.00
0
2
0
0
1
0
0
1
0
0
1
0
0
3
2
0
5
0
0
1
0
0
10
6
0
10
2
0
10
3
ID
Description
111
Find this value f
on the nameplate of the motor.
n
112
Find this value n
on the nameplate of the mo-
n
tor.
113
Find this value I
on the nameplate of the motor.
n
120
Find this value on the nameplate of the motor.
631
0 = No action
1 = At standstill
2 = With rotation
505
0 = Ramping
1 = Flying Start
506
0 = Coasting
1 = Ramping
731
0 = Disabled
1 = Enabled
701
0 = No action
1 = Alarm
2 = Fault (Stop according to stop mode)
3 = Fault (Stop by coasting)
700
0 = No action
1 = Alarm
2 = Alarm+preset fault frequency (P3.9.1.1)
3 = Alarm + previous frequency
4 = Fault (Stop according to stop mode)
5 = Fault (Stop by coasting)
172
0 = I/O control
1 = Fieldbus control
117
1 = Preset Frequency 0
2 = Keypad Reference
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1+AI2
7 = PID Reference
8 = Motor Potentiometer
9 = Joystick Reference
10 = Jogging Reference
121
See P1.19.
122
See P1.19.
