VACON® 3000
Application Guide
Index Monitoring value
V2.12.5.3 Power on state fault
V2.12.5.4 Power on status word fault
V2.12.5.5 Precharge status word fault
V2.12.5.6 Precharge error flags @ fault
PreStart OK requires that all of the following status words are OK: MCB Status (ID 3570), Leak Det. Status (ID 3571), GSW UFES Status (ID 3575), and
1
DC Cap Status (ID 3584).
Cooling OK requires that all of the following status words are OK: Enc HX Status (ID 3572), and HEX Status (ID 3573).
2
Table 19: Interlocks Monitoring Values
Index Monitoring value
V2.12.6.1 GSW UFES status word
V2.12.6.2 MCB status word
V2.12.6.3 Leak detection status word
44 | Danfoss A/S © 2021.09
Unit Scale ID
1 3521
1 3583
1 3514
1 3580
Unit Scale ID
1 3575
1 3570
1 3571
INU Application
Description
b13 = Cooling OK
(2)
b14 = DC Capacitors OK (INU)
See ID 3520.
See ID 3574.
See ID 3513.
See ID 3568 in Table 17.
Description
b0 = GSW Open 1
b1 = GSW Open 2
b2 = GSW Open 3
b3 = GSW Open 4
b4 = GSW Not Closed 1
b5 = GSW Not Closed 2
b6 = GSW Not Closed 3
b7 = GSW Not Closed 4
b12 = AFR Online
b13 = AFR Not Faulted
b14 = DSI Ok
b0 = ENC HX MCB 1
b1 = ENC HX MCB 2
b2 = ENC HX MCB 3
b3 = ENC HX MCB 4
b4 = TEMPCL MCB 1
b5 = TEMPCL MCB 2
b6 = TEMPCL MCB 3
b7 = TEMPCL MCB 4
b8 = Interlock Open 1
b9 = Interlock Open 2
b10 = Interlock Open 3
b11 = Interlock Open 4
b12 = Interlock Close 1
b13 = Interlock Close 2
b14 = Interlock Close 3
b0 = LD Sys Ok 1
b1 = LD Sys Ok 2
b2 = LD Sys Ok 3
b3 = LD Sys Ok 4
b4 = LD No Leak 1
b5 = LD No Leak 2
