4.4 Monitor Menu

4.4.1 Basic Monitoring

4.4.1.1 Uses of the Basic Monitoring

Only the standard I/O board statuses are available in the Monitor menu. For the statuses of all the I/O board signals as raw data, see
the I/O and Hardware menu.
Check the statuses of the expander I/O board in the I/O and Hardware menu when the system asks.

4.4.1.2 Basic Monitoring Parameters

Table 7: Items in the Basic Monitoring Menu
Index Monitoring value
V2.3.1 Output frequency
V2.3.2 Frequency reference
V2.3.3 Motor speed
V2.3.4 Motor current
V2.3.5 Motor torque
V2.3.7 Motor shaft power
V2.3.8 Motor shaft power
V2.3.9 Motor voltage
V2.3.10 DC-link voltage
V2.3.11 Unit temperature
