Shows only the parameters for the outputs on option boards in slots C, D, and E. Make the selections as in Basic AO1 Function
(P3.5.4.1.1). This group or these parameters are not visible if there are no digital outputs in slots C, D, or E.
Table 162: Analog Output Settings on Standard I/O board
Index Parameter
P3.5.4.1.1 AO1 function
P3.5.4.1.2 AO1 filter time
P3.5.4.1.3 AO1 minimum signal
P3.5.4.1.4 AO1 minimum scale
P3.5.4.1.5 AO1 maximum scale

5.5.6 Group 3.6: Fieldbus Data Mapping

Table 163: Fieldbus Data Mapping parameters
Index Parameter
P3.6.1 Fieldbus Data Out 1 Selection
P3.6.2 Fieldbus Data Out 2 Selection
P3.6.3 Fieldbus Data Out 3 Selection
P3.6.4 Fieldbus Data Out 4 Selection
P3.6.5 Fieldbus Data Out 5 Selection
Danfoss A/S © 2021.09
N O T I C E
Min Max Unit Default
2
0 31
1.00
0.0 300.0 s
0
0 1
0.00
Hz
0.00
Hz
Min Max
0 35000
0 35000
0 35000
0 35000
0 35000
ID Description
10050 0 = TEST 0%
1 = TEST 100%
2 = Output freq (0 - fmax)
3 = Freq reference (0 - fmax)
4 = Motor speed (0 - Motor nominal speed)
5 = Output current (0 - InMotor)
6 = Motor torque (0 - TnMotor)
7 = Motor power (0 - PnMotor)
8 = Motor voltage (0 - UnMotor)
9 = DC-link voltage (0 - 1000V)
10 = PID Setpoint (0-100%)
13 = ProcessDataIn1 (0-100%)
14 = ProcessDataIn2 (0-100%)
15 = ProcessDataIn3 (0-100%)
16 = ProcessDataIn4 (0-100%)
17 = ProcessDataIn5 (0-100%)
18 = ProcessDataIn6 (0-100%)
19 = ProcessDataIn7 (0-100%)
20 = ProcessDataIn8 (0-100%)
10051 0 = No filtering
10052 0 = 0 mA / 0 V
1 = 4 mA / 2 V
10053
10054
Unit Default ID
5515 852
74 853
37 854
37 855
56 856
