5.4.4 Maintenance Counters

Table 124: Maintenance Counter Monitoring
Index Monitoring value
V2.7.1 Maintenance Counter 1

5.4.5 Fieldbus Process Data Monitoring

Table 125: Fieldbus Process Data Monitoring
Index Monitoring value
V2.8.1 FB Control Word
V2.8.2 FB status word
V2.8.3 FB Speed Reference
V2.8.4 FB Speed Actual
V2.8.5 FB general control word
V2.8.6 FB general status word
M2.8.7 Data In
M2.8.8 Data Out
Table 126: Data In Monitoring
Index Monitoring value
V2.8.7.1 FB Data In 1
V2.8.7.2 FB Data In 2
V2.8.7.3 FB Data In 3
V2.8.7.4 FB Data In 4
V2.8.7.5 FB Data In 5
V2.8.7.6 FB Data In 6
V2.8.7.7 FB Data In 7
V2.8.7.8 FB Data In 8
V2.8.7.9 FB Data In 9
V2.8.7.10 FB Data In 10
V2.8.7.11 FB Data In 11
V2.8.7.12 FB Data In 12
V2.8.7.13 FB Data In 13
V2.8.7.14 FB Data In 14
V2.8.7.15 FB Data In 15
V2.8.7.16 FB Data In 16
Danfoss A/S © 2021.09
Unit Scale
h/kRev Varies
Unit Scale
1
1
Hz 0.01
% 0.01
1
1
Unit Scale
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
AFE Application
ID Description
1101
ID Description
874
864
875
865
861
862
See Table 126
See Table 127
ID Description
876
877
878
879
880
881
882
883
229
230
231
232
233
234
235
236
