VACON® 3000
Application Guide
Index Monitoring value
V2.10.4.12 Encoder Index Position
V2.10.4.13 Encoder Marker Position
V2.10.4.14 Encoder Alternate Marker Position

4.4.7 Precharge Monitoring

Table 17: Precharge Monitoring Values
Index Monitoring value
V2.12.1 Precharge state
V2.12.2 Precharge inhibit
V2.12.3 Precharge error flags
42 | Danfoss A/S © 2021.09
Unit Scale
1
1
1
Unit Scale ID Description
1 3510
0 = Reset
1 = Failed
2 = Not Ready
3 = Ready
4 = Charging
5 = Synchronizing
6 = Contactor Close
7 = Stabilizing
8 = Operational
9 = Loaded
1 3511
1 3568
b0 = Software
b1 = Main Pilot Open TO
b2 = Mx Open TO
b3 = PC Contactor Open TO
b4 = DC-link Discharge TO
b5 = Front End Fault Clear TO
b6 = DC-link Overvoltage
b7 = Front End Lost Phase Lock
b8 = Front End Faulted
b9 = Mx Premature Close
b10 = Main Pilot Premature Close
b11 = Precharge Premature Termination
b12 = Max Charge Rate Exceeded
b13 = Min Charge Rate Deficient
b14 = Precharge TO
b15 = DC-link Voltage Deficient
b16 = Synchronization TO
b17 = Main Pilot Close TO
b18 = Front End Lost Synchronization
b19 = Mx Close TO
b20 = Mx Premature Open
b21 = Stabilization TO
b22 = Front End Deactivated
b23 = Front End Lost Stabilization
b24 = Unexpected Parameterization
b25 = Invalid Parameterization
b26 = Test Mode Activated While Hot
b27 = INU Became Faulted
ID Description
3081
3082
3083
AB319735759636en-000101 / DPD01822
INU Application
