• 1: Standard.
• 2: Bypass.
7.578 (ID 10050) AO1 Function
Location in the menu:
• INU application: P3.5.4.1.1
• AFE application: P3.5.4.1.1
• BCU application: P3.4.4.1.1
Use this parameter to select a function or a signal that is connected to the analog output. The contents of the analog output signal 1
are specified in this parameter. The scaling of the analog output signal depends on the signal.
Selection num- Selection name
ber
0 Test 0% (Not used)
1 TEST 100%
2 Output frequency
3 Frequency reference
4 Motor speed
5 Output current
6 Motor torque
7 Motor power
8 Motor voltage
9 DC-link voltage
10 PID Setpoint
11 PID Feedback
12 PID output
13 Fieldbus Process Data In 1
14 Fieldbus Process Data In 2
15 Fieldbus Process Data In 3
16 Fieldbus Process Data In 4
17 Fieldbus Process Data In 5
18 Fieldbus Process Data In 6
19 Fieldbus Process Data In 7
20 Fieldbus Process Data In 8
Selection num- Selection name
ber
0 Test 0% (Not used)
1 TEST 100%
262 | Danfoss A/S © 2021.09
Description
The analog output is set to 0% or 20% so that it agrees with parameter P3.5.4.1.3.
The analog output is set to 100% of the signal (10V / 20mA).
The actual output frequency from 0 to Maximum frequency reference.
The actual frequency reference from 0 to Maximum frequency reference.
The actual motor speed from 0 to Motor nominal speed.
The output current of the drive from 0 to Motor nominal current.
The actual motor torque from 0 to motor nominal torque (100%).
The actual motor power from 0 to Motor nominal power (100%).
The actual motor voltage from 0 to Motor nominal voltage.
The actual DC-link voltage 0...1000 V.
The actual setpoint value of the PID Controller (0...100%).
The actual feedback value of the PID Controller (0...100%).
The output of the PID controller (0...100%).
Fieldbus Process Data In 1: 0...10000 (this agrees with 0... 100.00%).
Fieldbus Process Data In 2: 0...10000 (this agrees with 0... 100.00%).
Fieldbus Process Data In 3: 0...10000 (this agrees with 0... 100.00%).
Fieldbus Process Data In 4: 0...10000 (this agrees with 0... 100.00%).
Fieldbus Process Data In 5: 0...10000 (this agrees with 0... 100.00%).
Fieldbus Process Data In 6: 0...10000 (this agrees with 0... 100.00%).
Fieldbus Process Data In 7: 0...10000 (this agrees with 0... 100.00%).
Fieldbus Process Data In 8: 0...10000 (this agrees with 0... 100.00%).
Description
The analog output is set to 0% or 20% so that it agrees with parameter P3.5.4.1.3.
The analog output is set to 100% of the signal (10V / 20mA).
