VACON® 3000
Application Guide
Index Monitoring value
V2.10.6.2 MCB status word
V2.10.6.3 Leak detection status word
V2.10.6.4 ENC HX status word
V2.10.6.5 HEX status word
Danfoss A/S © 2021.09
Unit Scale ID
1 3570
1 3571
1 3572
1 3573
AFE Application
Description
b13 = AFR Not Faulted
b14 = DSI Ok
b15 = Always TRUE
b0 = ENC HX MCB 1
b1 = ENC HX MCB 2
b2 = ENC HX MCB 3
b3 = ENC HX MCB 4
b4 = TEMPCL MCB 1
b5 = TEMPCL MCB 2
b6 = TEMPCL MCB 3
b7 = TEMPCL MCB 4
b8 = Interlock Open 1
b9 = Interlock Open 2
b10 = Interlock Open 3
b11 = Interlock Open 4
b12 = Interlock Close 1
b13 = Interlock Close 2
b14 = Interlock Close 3
b15 = Interlock Close 4
b0 = LD Sys Ok 1
b1 = LD Sys Ok 2
b2 = LD Sys Ok 3
b3 = LD Sys Ok 4
b4 = LD No Leak 1
b5 = LD No Leak 2
b6 = LD No Leak 3
b7 = LD No Leak 4
b0 = ENC HX 1
b1 = ENC HX 2
b2 = ENC HX 3
b3 = ENC HX 4
b4 = ENC FAN 1.1
b5 = ENC FAN 1.2
b6 = ENC FAN 1.3
b7 = ENC FAN 2.1
b8 = ENC FAN 2.2
b9 = ENC FAN 2.3
b10 = ENC FAN 3.1
b11 = ENC FAN 3.2
b12 = ENC FAN 3.3
b13 = ENC FAN 4.1
b14 = ENC FAN 4.2
b15 = ENC FAN 4.3
b0 = HX Cooling Ok 1
b1 = HX Cooling Ok 2
b2 = HX Cooling Ok 3
