VACON® 3000
Application Guide
Index Parameter
P5.9.1.4 Ethernet Fieldbus 1
P5.9.1.5 Ethernet Fieldbus 2
M5.9.1.6 Fixed IP
V5.9.1.7 Speed/duplex
V5.9.1.8 IP address
V5.9.1.9 Subnet mask
V5.9.1.10 Default gateway
V5.9.1.11 MAC address
V5.9.1.12 Packet rate
V5.9.1.13 Peak packet rate
Depends on fieldbuses included in drive configuration
1
Table 186: Fixed IP
Index Parameter
P5.9.1.6.1 IP address
P5.9.1.6.2 Subnet mask
P5.9.1.6.3 Default gateway
Table 187: Fieldbus General
Index Parameter
P5.13.1 Controlling Fieldbus
V5.13.2 Controlling Fieldbus

5.7.9 Fieldbus Redundancy

VACON® 3000 supports the usage of two fieldbus connections. The drive accepts control data only from the primary fieldbus. If the
primary fieldbus connection fails, the control can be automatically switched to a secondary fieldbus using the fieldbus redundancy
control. VACON® 3000 built-in fieldbus protocols support fieldbus redundancy control. The only exception is RS485 N2, which does
not support fieldbus redundancy. Recent firmware versions of fieldbus option boards also support fieldbus redundancy.
132 | Danfoss A/S © 2021.09
Min Max Unit Default
0 4 0
(1)
0 4 3
(1)
0 4
0 255
0 255
0 255
Min Max
Min Max
0 5
0 5
ID Description
2 = 10M FD
3 = 100M HD
4 = 100M FD
2622
2 Ethernet-based internal fieldbuses can be enabled
at a time. Select fieldbus from the list.
2623
0 = None
1 = PROFINET I/O
2 = EtherNet/IP
3 = Modbus TCP
4 = BACnet/IP
See Table 186.
Unit Default
Unit Default ID
0 2539
2610
AB319735759636en-000101 / DPD01822
AFE Application
ID Description
2529
2530
2531
Description
0 = Automatic
1 = Slot E
2 = PROFINET I/O
3 = EtherNet/IP
4 = Modbus TCP
5 = BACnet/IP
