VACON® 3000
Application Guide
Index Monitoring value
V2.3.12 Motor temperature
V2.3.13 Torque reference
V2.3.14 Output power

4.4.2 I/O Monitoring

Table 8: I/O Signal Monitoring
Index Monitoring value
V2.4.1 Slot A DIN 1, 2, 3
V2.4.2 Slot A DIN 4, 5, 6
V2.4.3 Slot B RO 1, 2, 3
V2.4.4 Analog input 1
V2.4.5 Analog input 2
V2.4.6 Analog input 3
V2.4.7 Analog input 4
V2.4.8 Analog input 5
V2.4.9 Analog input 6
V2.4.10 Slot A AO1

4.4.3 Extras and Advanced

Table 9: Monitoring of the advanced values
Index Monitoring value
V2.6.1 Drive Status Word
V2.6.2 Ready status
V2.6.3 Application Status Word1
36 | Danfoss A/S © 2021.09
Unit Scale
% 0.1
% 0.1
kW 1
Unit Scale ID
1 15
1 16
1 17
% 0.01 59
% 0.01 60
% 0.01 61
% 0.01 62
% 0.01 75
% 0.01 76
% 0.01 81
Unit Scale ID Description
1 43
B1 = Ready
B2 = Run
B3 = Fault
B6 = Run Enable
B7 = Alarm Active
B10 = DC current in stop
B11 = DC brake active
B12 = Run Request
B13 = Motor Regulator Active
1 78
B0 = Run Enable high
B1 = No fault active
B2 = Charge switch closed
B3 = DC voltage within limits
B4 = Power manager initialized
B5 = Power unit is not blocking start
B6 = System software is not blocking start
1 89
B0 = Interlock 1
B1 = Interlock 2
INU Application
ID Description
9
18
79
Description
Slot A.1 as default.
Slot A.2 as default.
Slot D.1 as default.
Slot D.2 as default.
Slot E.1 as default.
Slot E.2 as default.
AB319735759636en-000101 / DPD01822
