VACON® 3000
Application Guide
Index
Parameter
Min
P5.7.3
Menu Index
P5.7.4
Contrast
30
P5.7.5
Backlight
0
Time
4.7.7 Fieldbus
In the I/O and Hardware menu, there are the parameters that are related to fieldbus boards. You can find the instructions on how to
use these parameters in the related fieldbus manual.
Table 104: Fieldbus Menu Structure
Submenu level 1
RS-485
Ethernet
88 | Danfoss A/S © 2021.09
Max
Unit
De-
ID
fault
2499
70
%
50
830
60
min
5
818
Submenu level 2
Common settings
Common settings
Modbus TCP
Description
2 = Main menu
3 = Control page
4 = Multimonitor
Set a page to be the menu index. (The selection 1 in P5.7.2.)
Set the contrast of the display.
Set the time after which the backlight of the display turns off. If the
value is set to 0, the backlight is always on.
Submenu level 3
Protocol
IP address mode
Duplicate IP detect
Speed/Duplex
Ethernet Fieldbus 1
Ethernet Fieldbus 2
Fixed IP
Speed/Duplex
IP address
Subnet mask
Default gateway
MAC address
Packet rate
Peak packet rate
Common settings
Monitoring
INU Application
Submenu level 4
IP address
Subnet mask
Default gateway
Connection limit
Slave address
Communication timeout
IDMap
Control word
AB319735759636en-000101 / DPD01822
