VACON® 3000
Application Guide
Index
Parameter
P3.8.1.16
FB communication fault force
delay
P3.8.1.17
FB communication fault clear
delay
P3.8.1.18
FBWD delay
P3.8.1.19
FBWD fault mode
Table 167: AI low protection settings
Index
Parameter
P3.8.4.1
Analog Input Low Protection
P3.8.4.2
Analog Input Low Fault
Table 168: Thermal protection settings
Index
Parameter
Coolant temperature input selection
P3.8.5.1
Coolant scale minimum
P3.8.5.2
P3.8.5.3
Coolant scale maximum
P3.8.5.4
FB coolant decimal places
P3.8.5.5
DTM back compatibility mode
Danfoss A/S © 2021.09
Min
Max
Unit
Default
s
0.00
s
0.00
s
2.00
Min
Max
Unit
Default
0
2
2
0
5
0
Min
Max
0
14
0
1
0
1
ID
Description
751
752
1808
1807
See ID 701
ID
Description
767
0 = No protection
1 = Protection enabled in Run state
2 = Protection enabled in Run and Stop state
700
0 = No action
1 = Alarm
2 = Alarm + preset fault frequency (P3.9.1.1)
3 = Alarm + previous frequency reference
4 = Fault (Stop according to stop mode)
5 = Fault (Stop by coasting)
Unit
Default
ID
0
3308
°C
0.0
3366
°C
100.0
3367
0
3365
0
3307
AB319735759636en-000101 / DPD01822 | 123
AFE Application
Description
0 = Not used
1 = AI1
2 = AI2
3 = AI3
4 = AI4
5 = AI5
6 = AI6
7 = ProcessDataIn1
8 = ProcessDataIn2
9 = ProcessDataIn3
10 = ProcessDataIn4
11 = ProcessDataIn5
12 = ProcessDataIn6
13 = ProcessDataIn7
14 = ProcessDataIn8
0 = 2D
1 = 1D
0 = Disabled
