Table 85: Channel B Settings
Index
Parameter
P3.15.5.1
Input Control
P3.15.5.2
Input AB Swap
P3.15.5.3
Encoder Debounce Time
P3.15.5.4
Marker Debounce Time
P3.15.5.5
Marker Event Mode
P3.15.5.6
Encoder Mode
P3.15.5.7
Resolution Prescale
P3.15.5.8
Hysteresis Filter Prescale
P3.15.5.9
Encoder Resolution
P3.15.5.10
Motor Pole Pairs
P3.15.5.11
Offset Mode
78 | Danfoss A/S © 2021.09
Min
Max
Unit
0
255
0
1
0
3400
ns
0
3400
ns
0
2
0
3
1
16
0
14
0
524288
0
255
0
2
De-
ID
Description
fault
0
3030
1 = Input A: Single Ended Signaling
2 = Input A: Active Low Signaling
4 = Input B: Single Ended Signaling
8 = Input B: Active Low Signaling
16 = Input Z: Single Ended Signaling
32 = Input Z: Active Low Signaling
64 = Input M: Single Ended Signaling
128 = Input M: Active Low Signaling
0
3031
0 = No
1 = Yes
250
3032
250
3033
0
3034
0 = Input M Rising Edge
1 = Input M, Gated by Z
2 = Input Z Rising Edge
0
3035
0 = Quadrature Mode
1 = Directional Pulse Mode
3 = Pulse + Direction Mode
0
3036
0
3037
Prescaler:
0 = /2
1 = /4
2 = /8
3 = /16
4 = /32
5 = /64
6 = /128
7 = /256
8 = /512
9 = /1024
10 = /2048
11 = /4096
12 = /8192
13 = /16384
14 = /32768
2048
3038
2
3039
0
3040
0 = Manual Offset
1 = Auto upon first Z pulse
2 = Auto upon first M pulse
