4.5.6 Group 3.6: Fieldbus Data Mapping

Table 59: Fieldbus Data Mapping parameters
Index Parameter
P3.6.1 Fieldbus Data Out 1 Selection
P3.6.2 Fieldbus Data Out 2 Selection
P3.6.3 Fieldbus Data Out 3 Selection
P3.6.4 Fieldbus Data Out 4 Selection
P3.6.5 Fieldbus Data Out 5 Selection
P3.6.6 Fieldbus Data Out 6 Selection
P3.6.7 Fieldbus Data Out 7 Selection
P3.6.8 Fieldbus Data Out 8 Selection
P3.6.9 Fieldbus Data Out 9 Selection
P3.6.10 Fieldbus Data Out 10 Selection
P3.6.11 Fieldbus Data Out 11 Selection
P3.6.12 Fieldbus Data Out 12 Selection
P3.6.13 Fieldbus Data Out 13 Selection
P3.6.14 Fieldbus Data Out 14 Selection
P3.6.15 Fieldbus Data Out 15 Selection
P3.6.16 Fieldbus Data Out 16 Selection
P3.6.17 Fieldbus Data In 1 Selection
P3.6.18 Fieldbus Data In 2 Selection
P3.6.19 Fieldbus Data In 3 Selection
P3.6.20 Fieldbus Data In 4 Selection
P3.6.21 Fieldbus Data In 5 Selection
P3.6.22 Fieldbus Data In 6 Selection
P3.6.23 Fieldbus Data In 7 Selection
P3.6.24 Fieldbus Data In 8 Selection
P3.6.25 Fieldbus Data In 9 Selection
P3.6.26 Fieldbus Data In 10 Selection
P3.6.27 Fieldbus Data In 11 Selection
64 | Danfoss A/S © 2021.09
Min Max Unit
0 35000
0 35000
0 35000
0 35000
0 35000
0 35000
0 35000
0 35000
0 35000
0 35000
0 35000
0 35000
0 35000
0 35000
0 35000
0 35000
INU Application
Default ID Description
1 852
2 853
3 854
4 855
5 856
6 857
7 858
37 859
0 890
0 891
0 892
0 893
0 894
0 895
0 896
0 897
0 6400
0 6401
0 6402
0 6403
0 6404
0 6405
0 6406
0 6407
0 6408
0 6409
0 6410
