VACON® 3000
Application Guide
4. To select a new item in the list, push [OK].

STOP
Output frequency
FreqReference
Motor Speed
Motor Current
Motor Torque
Motor Power

2.2.3 Editing the Text Values

This topic gives instructions on how to edit the text values on the graphical display.
Procedure
1. Find the parameter with the arrow buttons.
2.
To go to the Edit mode, push the [OK] button 2 times or push the arrow button Right.

STOP
Rem Control Place
Edit
Help
Add to favourites
3. To set a new value, push the arrow buttons Up and Down.

STOP
Rem Control Place
4.
To accept the change, push the [OK] button. To ignore the change, use the [BACK/RESET] button.

2.2.4 Editing the Numerical Values

This topic gives instructions on how to edit the numerical values on the graphical display.
Procedure
1. Find the parameter with the arrow buttons.
2.
To go to the Edit mode, push the [OK] button 2 times or push the arrow button Right.
14 | Danfoss A/S © 2021.09
READY I/O
FreqReference
ID:1 M2.1.1.1
0.00 Hz
10.00 Hz
0.00 rpm
0.00 A
0.00 %
0.00 %
READY I/O
ID: M3.2.1
READY I/O
ID: M3.2.1
FieldbusCTRL
I/O Control
User Interfaces
AB319735759636en-000101 / DPD01822
