Danfoss VACON 3000 Application Manual page 37

VACON® 3000
Application Guide
Index Monitoring value
V2.6.4 Application Status Word2
V2.6.5 DIN Status Word 1
V2.6.6 DIN Status Word 2
V2.6.7 Motor current 1 decimal
V2.6.8 Frequency reference source
V2.6.9 Last active fault code
V2.6.10 Last active fault ID
V2.6.11 Last active alarm code
V2.6.12 Last active alarm ID
V2.6.13 Motor regulator status
Danfoss A/S © 2021.09
Unit Scale ID Description
B2 = Reserved
B3 = Ramp 2 active
B4 = Mechanical brake control
B5 = I/O A control active
B6 = I/O B control active
B7 = Fieldbus Control Active
B8 = Local control active
B9 = PC control active
B10 = Preset frequencies active
B11 = Jogging active
B13 = Motor Preheat active
B14 = Quick stop active
B15 = Drive stopped from keypad
1 90
B0 = Acc/Dec prohibited
B1 = Motor switch open
B5 = Precharge ready
B6 = Precharge inhibit
B7 = Precharge started
B8 = Supervision 1
B9 = Supervision 2
1 56
1 57
0.1 45
1 1495
0 = PC
1 = Preset Freqs
2 = Keypad Reference
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1+AI2
7 = PID Controller
8 = Motor Potentiometer
9 = Joystick
10 = Jogging
100 = Not defined
101 = Alarm,PresetFreq
1 37
1 95
1 74
1 94
1 77
B0 = Current Limit (Motor)
B1 = Current Limit (Generator)
B2 = Torque Limit (Motor)
B3 = Torque Limit (Generator)
INU Application
AB319735759636en-000101 / DPD01822 | 37
