VACON® 3000
Application Guide
Index Parameter
1.4 Grid Voltage Feedback Channel B
1.5 Grid Voltage Feedback Channel C
1.6 Grid Voltage Feedback Scale
1.7 Filter Topology
1.8 Regen Filter Select
1.9 Special Filter Index

5.4 Monitor Menu

5.4.1 AFE Monitor

Table 118: AFE Monitoring
Index Monitoring value
M2.3.1 DC link
M2.3.2 Line PLL
M2.3.3 Line filter observer
V2.3.5 Precharge state
Table 119: DC-Link Monitoring
Index Monitoring value
V2.3.1.1 DC-link voltage
96 | Danfoss A/S © 2021.09
Min Max Unit
0 12
0 12
-10000.0 10000.0
0 2
0 8
Unit Scale
1
Unit
V
Default ID Description
8 = BA Line Voltage
9 = BC Line Voltage
10 = CB Line Voltage
11 = CA Line Voltage
12 = AC Line Voltage
0 5022 See ID 5020 above
9 5023 See ID 5020 above
120.0000 5024
0 5030
0 5039
0 = Special
1 = L20.3
2 = L20.3 HSI
3 = L20.4
4 = L20.4 HSI
5 = L30.3
6 = L30.3 HSI
7 = L30.4
8 = L30.4 HSI
21000 5040
ID Description
See Table 119.
See Table 120.
See Table 121.
3510
0 = Reset
1 = Failed
2 = Not Ready
3 = Ready
4 = Charging
5 = Synchronizing
6 = Contactor Close
7 = Stabilizing
8 = Operational
9 = Loaded
Scale ID Description
0.1 7
AB319735759636en-000101 / DPD01822
AFE Application
