Agilent Technologies E5071C Manual page 910

13
Trace 13 Bandwidth Test
Fail
14 Trace 14 Bandwidth Test
Fail
15 Not used
Issuing the command will clear all the bits in the questionable
*CLS
bandwidth limit channel {1-16} status event register.
Status Bit Definitions of the Questionable Bandwidth Limit Channel
{1-16} Extra Status Condition Register
Bit Name
Position
0 Not used
1 Trace 15
Bandwidth Test
Fail
2 Trace 16
Bandwidth Test
Fail
measurement cycle finishes
and returns "fail" as the
bandwidth test result for
trace 12.
Set to "0" when a
measurement cycle begins;
set to "1" when the
measurement cycle finishes
and returns "fail" as the
bandwidth test result for
trace 13.
Set to "0" when a
measurement cycle begins;
set to "1" when the
measurement cycle finishes
and returns "fail" as the
bandwidth test result for
trace 14.
Always 0
Description
Always 0
Set to "0" when a measurement cycle
begins;
set to "1" when the measurement cycle
finishes and returns "fail" as the
bandwidth test result for trace 15.
Set to "0" when a measurement cycle
begins;
set to "1" when the measurement cycle
finishes and returns "fail" as the
bandwidth test result for trace 16.
Programming
1137
