Summary of Contents for Agilent Technologies E5061B
Page 1
E5061B-05 S E R V I C E N O T E Supersedes: NONE E5061B Network Analyzer, 5 Hz to 3GHz Serial Numbers: MY49100100 to MY49299999, SG49100100 to SG49299999 Compatibility issue between Touch Screen Controller and HDD Parts Required: Description Qty.
Page 2
Page 2 of 8 E5061B-05 Situation: There is a compatibility issue between Touch Panel Controller and HDD. When the HDD needs to replace with the E5061-82202 with Serial-Number Range from MY4910xxxx to MY4910xxxx and SG4910xxxx to SG4910xxxx, Touch Panel Controller and its related mechanical items (E5061-65001) also need to be replaced.
Page 3
E5061B DR-12 driver is in the HDD, but DR-12 HW is not in the E5061B Note: This combination failure detection is not available on FW A.02.03 or below. 5012-8672, DR-12 Touch Screen Controller board needs DR-12 driver on the HDD. The DR-12 driver is in the E5061-82201 HDD only.
Page 4
Page 4 of 8 E5061B-05 Case1:Touch Panel Case2: HDD is defective Controller is defective Serial-Number Combination of Replacement Warranty Replacement items Warranty Charge Range Touch Panel items Charge Controller and HDD Volume Label when the instrument was shipped MY49100001 to...
Page 5
Page 5 of 8 E5061B-05 1400-3337 Clamp-Cable E5061-61651 Wire Assembly E5061-61652 Bulkhead USB Cable Assembly 1400-3415 Wire Clamp 0363-0170 RFI Gasket The steps to replace from 5012-8672 to 0960-2972 are as follows. Step-1: Replace E5061-61617 with E5061-61627. Connect the both end connectors of the wire assembly part properly.
Page 6
1400-3415 Page 6 of 8 E5061B-05 Step-4: Pass the white connector of the cable through the new hole then return it through the current hole from behind. E5061-61651 Step-5: Insert another connector to the bracket next to the new hole.
Page 7
Page 7 of 8 E5061B-05 Step-7: Connect the cable E5061-61631(which is re-used item from the original instrument) and make a shape correctly as the picture. Step-8: Connect the cable to J18 port on the CPU board, then paste a cable clamp on the sidewall of the PSU as the picture.
Page 8
Page 8 of 8 E5061B-05 Step-11: Install the front assembly module to the chassis completely, then check cable caught between the front assembly module and the chassis visually. Next, fix the installed front assembly module with 7pcs of screw, 0515-1382.
