Digital camera interface (DCMI)
15.8.11 DCMI data register (DCMI_DR)
Address offset: 0x28
Reset value: 0x0000 0x0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
Byte3
r r r r r r r
Bits 31:24 Data byte 3
Bits 23:16 Data byte 2
The digital camera Interface packages all the received data in 32-bit format before
requesting a DMA transfer. A 4-word deep FIFO is available to leave enough time for DMA
transfers and avoid DMA overrun conditions.
15.8.12 DCMI register map
Table 87
Offset Register
DCMI_CR
0x00
Reset value
DCMI_SR
0x04
Reset value
DCMI_RIS
0x08
Reset value
DCMI_IER
0x0C
Reset value
DCMI_MIS
0x10
Reset value
478/1749
Byte2
r r r r r r
Bits 15:8 Data byte 1
Bits 7:0 Data byte 0
summarizes the DCMI registers.

Table 87. DCMI register map and reset values

Reserved
Byte1
r r r r r r r
Reserved
Reserved
Reserved
Reserved
