RM0090
3.9.5

Flash status register (FLASH_SR) for

STM32F405xx/07xx and STM32F415xx/17xx

The Flash status register gives information on ongoing program and erase operations.
Address offset: 0x0C
Reset value: 0x0000 0000
Access: no wait state, word, half-word and byte access
31 30 29 28
15 14 13 12
Reserved
Bits 31:17 Reserved, must be kept cleared.
Bit 16 BSY: Busy
This bit indicates that a Flash memory operation is in progress. It is set at the beginning of a
Flash memory operation and cleared when the operation finishes or an error occurs.
Bits 15:8 Reserved, must be kept cleared.
Bit 7 PGSERR: Programming sequence error
Set by hardware when a write access to the Flash memory is performed by the code while the
control register has not been correctly configured.
Cleared by writing 1.
Bit 6 PGPERR: Programming parallelism error
Set by hardware when the size of the access (byte, half-word, word, double word) during the
program sequence does not correspond to the parallelism configuration PSIZE (x8, x16, x32,
x64).
Cleared by writing 1.
Bit 5 PGAERR: Programming alignment error
Set by hardware when the data to program cannot be contained in the same 128-bit Flash
memory row.
Cleared by writing 1.
Bit 4 WRPERR: Write protection error
Set by hardware when an address to be erased/programmed belongs to a write-protected part
of the Flash memory.
Cleared by writing 1.
27 26 25
11 10 9
0: no Flash memory operation ongoing
1: Flash memory operation ongoing
24 23 22
Reserved
8 7 6
PGSERR PGPERR PGAERR WRPERR
rc_w1 rc_w1
RM0090 Rev 18
Embedded Flash memory interface
21 20 19
5 4 3
Reserved
rc_w1 rc_w1
18 17 16
BSY
r
2 1 0
OPERR EOP
rc_w1 rc_w1
101/1749
