General-purpose timers (TIM2 to TIM5)
Slave TIM
TIM2
TIM3
TIM4
TIM5
18.4.4 TIMx DMA/Interrupt enable register (TIMx_DIER)
Address offset: 0x0C
Reset value: 0x0000
15 14 13
TDE CC4DE CC3DE CC2DE CC1DE
Res. Res
rw
Bit 15
Bit 14 TDE: Trigger DMA request enable
Bit 13
Bit 12 CC4DE: Capture/Compare 4 DMA request enable
Bit 11 CC3DE: Capture/Compare 3 DMA request enable
Bit 10 CC2DE: Capture/Compare 2 DMA request enable
Bit 9 CC1DE: Capture/Compare 1 DMA request enable
Bit 8 UDE: Update DMA request enable
Bit 7
Bit 6 TIE: Trigger interrupt enable
Bit 5
Bit 4 CC4IE: Capture/Compare 4 interrupt enable
632/1749

Table 98. TIMx internal trigger connection

ITR0 (TS = 000)
TIM1_TRGO
TIM1_TRGO
TIM1_TRGO
TIM2_TRGO
12 11 10 9
rw rw rw rw
Reserved, must be kept at reset value.
0: Trigger DMA request disabled.
1: Trigger DMA request enabled.
Reserved, always read as 0
0: CC4 DMA request disabled.
1: CC4 DMA request enabled.
0: CC3 DMA request disabled.
1: CC3 DMA request enabled.
0: CC2 DMA request disabled.
1: CC2 DMA request enabled.
0: CC1 DMA request disabled.
1: CC1 DMA request enabled.
0: Update DMA request disabled.
1: Update DMA request enabled.
Reserved, must be kept at reset value.
0: Trigger interrupt disabled.
1: Trigger interrupt enabled.
Reserved, must be kept at reset value.
0: CC4 interrupt disabled.
1: CC4 interrupt enabled.
ITR1 (TS = 001)
TIM8_TRGO
TIM2_TRGO
TIM2_TRGO
TIM3_TRGO
8 7 6
UDE TIE
Res.
rw rw
RM0090 Rev 18
ITR2 (TS = 010) ITR3 (TS = 011)
TIM3_TRGO
TIM5_TRGO
TIM3_TRGO
TIM4_TRGO
5 4 3 2
CC4IE CC3IE CC2IE
Res
rw rw rw
RM0090
TIM4_TRGO
TIM4_TRGO
TIM8_TRGO
TIM8_TRGO
1 0
CC1IE UIE
rw rw
