Sp2-Xxx (Ram Data); Sp3-Xxx (Tel Line Settings) - Ricoh D037 Service Manual

Service Tables

4.2.2 SP2-XXX (RAM DATA)

2 Mode No.
RAM Read/Write
101
001
Memory Dump
102
001
G3-1 NCU Parameters
103
001 – 023

4.2.3 SP3-XXX (TEL LINE SETTINGS)

Mode No.
3
Service Station
101
001
Serial Number
102
000
103 PSTN-1 Port Settings
001
002
D432/D433
G3-1 Memory
Dump
CC, 01 – 22
Function
Fax Number Enter the fax number of the service station.
Enter the fax unit's serial number.
Select the line type setting for the G3-1 line. If
Select Line the machine is installed on a PABX line, select
"PABX", "PABX(GND)" or "PABX(FLASH)".
PSTN Access Enter the PSTN access number for the
Number G3-1 line.
Function
Change RAM data for the fax board directly.
"Service RAM Addresses"
Print out RAM data for the fax board.
"Service RAM Addresses"
NCU parameter settings for the standard G3
board. "NCU Parameters"
48 SM
