Table 1-3 Description on the fields of the display vlan command
Interface
VLAN ID
Protocol-Index
Protocol-type

display protocol-vlan vlan

Syntax
display protocol-vlan vlan { vlan-id1 [ to vlan-id2 ] | all }
View
Any view
Parameters
vlan-id1: Specifies a VLAN ID in the range of 1 to 4094, of which the protocol VLAN configuration
information is to be displayed.
to vlan-id2: In conjunction with vlan-id1, define a VLAN range to display the protocol template
configurations of all protocol VLANs in the range. The vlan-id2 argument takes a value in the range of 1
to 4094, and must not be less than that of vlan-id1.
all: Displays all protocol VLANs and their protocol template information.
Description
Use the display protocol-vlan vlan command to display information about protocol VLANs.
Related commands: protocol-vlan.
Examples
# Display the protocol information and protocol indexes configured for VLAN 10 through VLAN 20.
<Sysname> display protocol-vlan vlan 10 to 20
VLAN ID: 10
VLAN Type: Protocol-based VLAN
Protocol-Index
0
1
2
3
VLAN ID: 15
VLAN Type: Protocol-based VLAN
Protocol-Index
0
4 llc dsap 0xac ssap 0xbd
Field
Protocol-Type
ip
ip
ipx ethernetii
at
Protocol-Type
ip
1-16
Description
Interface bound with at least one protocol VLAN
ID of a protocol VLAN bound with the interface
Protocol template index
Protocol type specified by the protocol template.
Refer to the protocol-vlan command for
detailed description.
