Display Packet-Filter - H3C s3600 series Command Manual

Table 1-2 Description on the fields of the display drv qacl_resource command
Field
block
used-mask
used-rule
spare-mask
spare-rule
# Apply ACL 2001 to port GigabitEthernet 1/1/1.
<Sysname> system-view
System View: return to User View with Ctrl+Z.
[Sysname] interface GigabitEthernet 1/1/1
[Sysname-GigabitEthernet1/1/1] packet-filter inbound ip-group 2001
Applying Acl 2001 rule 0 failed!
The above output information shows that the application failed because there is no available rule
resource on port GigabitEthernet 1/1/1.

display packet-filter

Syntax
display packet-filter { interface interface-type interface-num | unitid unit-id }
View
Any view
Parameters
interface interface-type interface-number: Displays information about packet filtering on the specified
port.
unitid unit-id: Displays information about packet filtering on the specified unit (when the switch is in a
fabric) or packet filtering on all ports of the current switch (when the switch is not in a fabric). In the
former case, the unit-id argument is in the range 1 to 8; in the latter case, the unit-id argument can only
be 1.
Description
Use the display packet-filter command to display information about packet filtering.
Examples
# Display information about packet filtering on all ports of a switch that is not in a fabric.
<Sysname> display packet-filter unitid 1
On the front panel,
From left to right, every four columns of FE ports (total of eight FE ports)
represents a block numbered starting from 0. That is, 0 indicates Ethernet
1/0/1 to Ethernet 1/0/8, 1 indicates Ethernet 1/0/9 to Ethernet 1/0/16, and
2 indicates Ethernet 1/0/17 to Ethernet 1/0/24.
Every GE port represents a block numbered starting from 6. That is, 6
indicates GigabitEthernet 1/1/1, 7 indicates GigabitEthernet 1/1/2, 8
indicates GigabitEthernet 1/1/3, and 9 indicates GigabitEthernet 1/1/4.
Number of the used masks
Number of the used rules
Number of the remaining masks
Number of the remaining rules
Reason: Resource unavailable!(GigabitEthernet1/1/1)
1-5
Description
