H3C s3600 series Command Manual page 602

Field
Quiet period
Server response timeout value
Guest VLAN re-authenticate period
Max allowed user number
Current user number amounts to
Current domain
Silent Mac User info
Ethernet1/0/1 is link-up
MAC address authentication is Enabled
max-auth-num
Guest VLAN
Authenticate success: 1, failed: 0
Current online user number
MAC ADDR
Authenticate state
AuthIndex
Description
Quiet timer sets the quiet period. A switch goes through
a quiet period if a user fails to pass the MAC address
authentication. The default value is 60 seconds.
Server timeout timer, which sets the timeout time for the
connection between a switch and the RADIUS server.
By default, it is 100 seconds.
Re-authenticate timer, which sets the time interval to
reauthenticate the users in the Guest VLAN and
defaults to 30 seconds.
The maximum number of users supported by the switch.
It is 1,024 by default.
The current number of users
The current domain. It is not configured by default.
The information about the silent user. When the user
fails to pass MAC address authentication because of
inputting error user name and password, the switch sets
the user to be in quiet state. During quiet period, the
switch does not process the authentication request of
this user.
The link connected to Ethernet1/0/1 port is up.
MAC address authentication is enabled for
Ethernet1/0/1 port.
Maximum number of MAC address authentication users
that the port can accommodate
Guest VLAN of the port
Statistics of the MAC address authentications
performed on the port, including the numbers of
successful and failed authentication operations.
The number of the users current access the network
through the port
Peer MAC address
The state of the users accessing the network through
the port, which can be:
MAC_AUTHENTICATOR_CONNECTING:
Connecting
MAC_AUTHENTICATOR_SUCCESS:
Authentication passed
MAC_AUTHENTICATOR_FAILURE: Fail to pass
authentication
MAC_AUTHENTICATOR_LOGOFF: Offline
Index of the current MAC address with regard to the
authentication port
1-3
