View
QoS profile view
Parameters
inbound: Performs priority marking on the inbound packets.
outbound: Performs priority marking on the outbound packets.
acl-rule: ACL rules to be applied for traffic classification. This argument can be the combination of
multiple ACLs. For more information about this argument, refer to
ACL rules referenced must be those defined with the permit keyword.
dscp dscp-value: Sets the DSCP precedence, in the range 0 to 63. You can also provide one of the
keywords listed in
ip-precedence { pre-value | from-cos }: Sets the IP precedence. The pre-value argument ranges from
0 to 7. You can also provide one of the keywords listed in
from-cos keyword specifies to use the 802.1p priority as the IP precedence.
cos { pre-value | from-ipprec }: Sets the 802.1p priority. The pre-value argument is in the range 0 to 7.
You can also provide one of the keywords listed in
from-ipprec keyword specifies to use the IP precedence as the 802.1p priority.
local-precedence pre-value: Sets the local precedence value, in the range of 0 to 7.
Description
Use the traffic-priority command to add a priority marking action to a QoS profile.
Use the undo traffic-priority command to remove a priority marking action from a QoS profile.
Do not configure 802.1p priority marking and local precedence marking for the same traffic. With 802.1p
priority marking, the new 802.1p priority will be mapped to a local precedence automatically. If local
precedence marking is also configured, there will be two local precedence values for the traffic,
resulting in conflict. In this case, the device will display an error prompt.
Examples
# Add the priority marking action to the QoS profile named a123 to set the local precedence of the
inbound packets sourced from IP address 1.1.1.1 to 0.
<Sysname> system-view
System View: return to User View with Ctrl+Z.
[Sysname] acl number 2000
[Sysname-acl-basic-2000] rule permit source 1.1.1.1 0
[Sysname-acl-basic-2000] quit
[Sysname] qos-profile a123
[Sysname-qos-profile-a123] traffic-priority inbound ip-group 2000 local-precedence 0
Table 1-7 for the dscp-value argument.
Table 1-4
Table 1-6
Table 1-10 for the pre-value argument. The
2-8
and Table 1-5. Note that the
for the pre-value argument. The
