Note that, the collection of candidate/member devices are based on NTDP. Therefore, you must first
enable NTDP. In addition, you can use the ntdp hop command in system view to change the collection
range.
When the system automatically adds a device to the cluster, if the user password configured for the
device is different from that of the management device, the device cannot be added to the cluster.
After a cluster is built automatically, ACL 3998 and ACL 3999 will automatically generate a rule
respectively to prohibit packets whose source and destination addresses are private IP addresses
of the cluster from being sent to or received from the public network. The two ACL rules will be
automatically applied to all ports of the cluster members.
After a cluster is built automatically, ACL 3998 and ACL 3999 can neither be configured/modified
nor removed.
Examples
# Start an automatic cluster building process.
<Sysname> system-view
System View: return to User View with Ctrl+Z.
[Sysname] cluster
[Sysname-cluster] auto-build
There is no base topology, if set up from local flash file?(Y/N)
n
Please input cluster name:aaa
Collecting candidate list, please wait...
#Apr 3 08:12:32:832 2000 aaa_0.Sysname CLST/5/Cluster_Trap:- 1 -
OID:1.3.6.1.4.1.2011.6.7.1.0.3(hgmpMemberStatusChange):member 00.00.00.00.00.12.
a9.90.22.40 role change, NTDPIndex:0.00.00.00.00.00.12.a9.90.22.40, Role:1
Candidate list:
Name
H3C
H3C
H3C
SwitchA
H3C
H3C
H3C
H3C
Processing...please wait
%Apr 3 08:12:37:813 2000 aaa_0.Sysname CLST/5/LOG:- 1 -
Hops MAC Address
2 0016-e0c0-c201
2 000f-e221-616e
2 000f-e202-2180
2 0016-e0be-e200
3 000f-e200-1774
2 000f-e200-5600
3 000f-e200-5104
2 000f-e200-2420
1-15
Device
H3C S3600-28F-EI
H3C S3600-28F-EI
H3C S3600-28P-SI
H3C S5600-26C
H3C S5600-26F
H3C S5600-26F
H3C S3600-28P-SI
H3C S3600-28P-SI
