display irf-fabric

Syntax
display irf-fabric [ port | status ]
View
Any view
Parameters
port: Displays the fabric port information.
status: Displays operation status of the current fabric, including fabric name and unit ID.
Description
Use the display irf-fabric command to view the information of the entire fabric, including unit ID, unit
name, and operation mode of the system. If the fabric information is displayed on the console port of a
device, an asterisk (*) will be added to the unit ID of the current device.
Examples
# Display fabric information on the console port of unit 1.
<Sysname> display irf-fabric
Fabric name is Sysname, system mode is L3.
Unit Name
First
Second
From the above example, you can see the following:
The name of the fabric is Sysname.
The system operation mode is Layer 3 forwarding.
The current device is 1 (marked by *)
The name of the current device is First (the name of a device can be configured by using the set
unit name command)
The other unit in the fabric is numbered 2
# Display fabric operation status on the console port of unit 1.
<Sysname> display irf-fabric status
Fabric name is Sysname, system mode is L3.
Unit Name
First
From the above example, you can see not only the information displayed by using the display irf-fabric
command, but also the roles of the units in the fabric (master or slave).
# Display the fabric port of the current device.
<Sysname> display irf-fabric port
GigabitEthernet1/1/1
Fabric peer: Unknown
Fabric Status:
Fabric mode: Unknown-speed mode, Unknown-duplex mode
Unknown
Unit ID
1(*)
2
Unit ID
1(*)
1-7
Status
Master
