H3C s3600 series Command Manual page 741

Parameters
lsap lsap-code
lsap-wildcard
source
{ source-mac-addr
source-mac-mask |
vlan-id }*
dest dest-mac-addr
dest-mac-mask
cos cos
c-tag-vlan
c-tag-vlan-begin [ to
c-tag-vlan-end ]
time-range
time-name
type protocol-type
protocol-mask
When layer 2 ACLs are applied to ports or VLANs of the H3C S3600 series Ethernet switches, rules
configured with the format-type argument and the lsap keyword are invalid.
Type
lsap field
Source MAC address
information or source
VLAN information
Destination MAC
address information
Priority
Inner VLAN
information
Time range
information
Protocol type of
Ethernet frames
1-19
Function
Specifies the lsap
field for the ACL rule
Specifies the source
MAC address range
or source VLAN ID for
the ACL rule
Specifies the
destination MAC
address range for the
ACL rule
Specifies the 802.1p
priority of the rule
Specifies information
about inner VLAN of
the rule
Specifies the time
range in which the
rule takes effect.
Specifies the protocol
type of Ethernet
frames for the ACL
rule
Description
lsap-code: Encapsulation
format of data frames, a
16-bit hexadecimal
number.
lsap-wildcard: Mask of the
lsap value, a 16-bit
hexadecimal number used
to specify the mask bits.
source-mac-addr: Source
MAC address, in the
format of H-H-H.
source-mac-mask: Mask
of the source MAC
address, in the format of
H-H-H.
vlan-id: Source VLAN ID,
in the range of 1 to 4,094.
dest-mac-addr:
Destination MAC address,
in the format of H-H-H.
dest-mac-mask: Mask of
the destination MAC
address, in the format of
H-H-H.
cos: VLAN priority, in the
range of 0 to 7.
c-tag-vlan-begin,
c-tag-vlan-end: VLAN ID,
in the range of 1 to 4094.
This keyword and
argument combination is
usually used in
cooperation with the QinQ
function. For information
about QinQ, refer to
VLAN-VPN Operation.
time-name: specifies the
name of the time range in
which the rule is active; a
string comprising 1 to 32
characters.
protocol-type: Protocol
type.
protocol-mask: Protocol
type mask.
