Exception Model

Table 5-6. Transactions Reflected to the Processor for Snooping (Continued)
Snooped Transaction
Write-with-flush
Write-with-flush-atomic
Write-with-kill
5.5 Exception Model
This section describes the PowerPC exception model and implementation-specific details
of the MPC8240 core.
5.5.1 PowerPC Exception Model
The PowerPC exception mechanism allows the processor to change to supervisor state as a
result of external signals, errors, or unusual conditions arising in the execution of
instructions. When exceptions occur, information about the state of the processor is saved
to certain registers and the processor begins execution at an address (exception vector)
predetermined for each exception. Processing of exceptions occurs in supervisor mode.
Although multiple exception conditions can map to a single exception vector, a more
specific condition may be determined by examining a register associated with the
exception. For example, the DSISR identifies instructions that cause a DSI exception.
Additionally, some exception conditions can be explicitly enabled or disabled by software.
The PowerPC architecture requires that exceptions be handled in program order; therefore,
although a particular implementation may recognize exception conditions out of order,
exceptions are taken in strict order. When an instruction-caused exception is recognized,
any unexecuted instructions that appear earlier in the instruction stream, including any that
have not yet entered the execute stage, are required to complete before the exception is
taken. Any exceptions caused by those instructions are handled first. Likewise, exceptions
that are asynchronous and precise are recognized when they occur, but are not handled until
the instruction currently in the completion stage successfully completes execution or
generates an exception, and the completed store queue is emptied.
Unless a catastrophic condition causes a system reset or machine check exception, only one
exception is handled at a time. If, for example, a single instruction encounters multiple
exception conditions, those conditions are handled sequentially. After the exception handler
handles an exception, the instruction execution continues until the next exception condition
5-26
Condition Detected by CCU
Non-locked PCI write to memory or
locked PCI write to memory,
respectively
Locked or non-locked PCI write with
invalidate to memory
MPC8240 Integrated Processor User's Manual
Processor Response
• If the addressed block is in the exclusive
state, the snoop forces the state of the
addressed block to invalid.
• If the addressed block is in the modified
state, the snoop causes a push of the modified
block out of the cache to memory and changes
the state of the block to invalid.
In a write-with-kill operation, the processor
snoops the cache for a copy of the addressed
block. If one is found the cache block is forced
to the I state, killing modified data that may
have been in the block.
