JUNOS 10.1 Network Interfaces Configuration Guide
You configure the various interface descriptors as follows:
Related Topics

Interface Naming Overview

Each interface has an interface name, which specifies the media type, the slot in
which the FPC or DPC is located, the location on the FPC where the PIC is installed,
and the PIC or DPC port. The interface name uniquely identifies an individual network
connector in the system. You use the interface name when configuring interfaces
and when enabling various functions and properties, such as routing protocols, on
individual interfaces. The system uses the interface name when displaying information
about the interface, for example, in the
The interface name is represented by a physical part, a channel part, and a logical
part in the following format:
The channel part of the name is optional for all interfaces except channelized DS3,
E1, OC12, and STM1 interfaces.
The following sections provide interface naming configuration guidelines:
52
Interface Naming Overview
You configure the physical interface descriptor by including the
statement.
interface-name
You configure the logical interface descriptor by including the
within the
interfaces interface-name
descriptor at the end of the interface name, as in
unit number is 1, as shown in the following examples:
[edit]
user@host# set interfaces t3-0/0/0 unit 1
[edit]
user@host# edit interfaces t3-0/0/0.1
[edit interfaces t3-0/0/0]
user@host# set unit 1
You configure the family descriptor by including the family statement within the
statement.
unit
You configure address entries by including the address statement within the
family statement.
You configure tunnels by including the tunnel statement within the
Router Interfaces Overview on page 32
physical<:channel>.logical
Physical Part of an Interface Name on page 53
Logical Part of an Interface Name on page 57
Separators in an Interface Name on page 57
Channel Part of an Interface Name on page 57
statement or by including the
t3-0/0/0.1 , where the logical
command.
show interfaces
interfaces
unit statement
.logical
statement.
unit
