RM0432
Bit 2 Reserved, must be kept at reset value.
Bit 1 EPDM: Endpoint disabled interrupt mask
Bit 0 XFRCM: Transfer completed interrupt mask
56.15.39 OTG device OUT endpoint common interrupt mask register
(OTG_DOEPMSK)
Address offset: 0x814
Reset value: 0x0000 0000
This register works with each of the OTG_DOEPINTx registers for all endpoints to generate
an interrupt per OUT endpoint. The OUT endpoint interrupt for a specific status in the
OTG_DOEPINTx register can be masked by writing into the corresponding bit in this
register. Status bits are masked by default.
31
30
29
Res.
Res.
Res.
Res.
15
14
13
NAK
BERR
Res.
Res.
MSK
rw
Bits 31:14 Reserved, must be kept at reset value.
Bit 13 NAKMSK: NAK interrupt mask
Bit 12 BERRM: Babble error interrupt mask
Bits 11:10 Reserved, must be kept at reset value.
Bit 9 Reserved, must be kept at reset value.
Bit 8 OUTPKTERRM: Out packet error mask
Bit 7 Reserved, must be kept at reset value.
Bit 6 Reserved, must be kept at reset value.
Bit 5 STSPHSRXM: Status phase received for control write mask
0: Masked interrupt
1: Unmasked interrupt
0: Masked interrupt
1: Unmasked interrupt
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
Res.
M
rw
0: Masked interrupt
1: Unmasked interrupt
0: Masked interrupt
1: Unmasked interrupt
0: Masked interrupt
1: Unmasked interrupt
0: Masked interrupt
1: Unmasked interrupt
USB on-the-go full-speed (OTG_FS)
24
23
22
Res.
Res.
Res.
8
7
6
OUT
PKT
Res.
Res.
PHSR
ERRM
rw
RM0432 Rev 6
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
STS
OTEPD
STUPM
Res.
XM
M
rw
rw
rw
17
16
Res.
Res.
1
0
XFRC
EPDM
M
rw
rw
2165/2301
