Goodrive350-19 series VFD for crane
Function
code
P10.12 Multi-step speed 5
P10.13 Running time of step 5
P10.14 Multi-step speed 6
P10.15 Running time of step 6
P10.16 Multi-step speed 7
P10.17 Running time of step 7
P10.18 Multi-step speed 8
P10.19 Running time of step 8
P10.20 Multi-step speed 9
P10.21 Running time of step 9
P10.22 Multi-step speed 10
P10.23 Running time of step 10
P10.24 Multi-step speed 11
P10.25 Running time of step 11
P10.26 Multi-step speed 12
P10.27 Running time of step 12
P10.28 Multi-step speed 13
P10.29 Running time of step 13
P10.30 Multi-step speed 14
P10.31 Running time of step 14
P10.32 Multi-step speed 15
P10.33 Running time of step 15
ACC/DEC time of steps 0–7
P10.34
ACC/DEC time of steps 8–15
P10.35
P10.36 PLC restart mode
P17.00
Simple PLC and actual step
P17.27
of multi-step speed

6.5.14 Multi-step speed running

Set the parameters used in multi-step speed running. The VFD can set 16-step speeds, which are
selectable by multi-step speed terminals 1–4, corresponding to multi-step speed 0 to multi-step speed
15.
Name
of simple PLC
of simple PLC
Set frequency
Description
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
0x0000–0XFFFF
0x0000–0XFFFF
0: Restart from step 1
1: Resume from the paused step
0.00Hz–P00.03 (Max. output frequency)
0–15
-189-
Basic operation guidelines
Default
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0000
0000
0
0.00Hz
0
