INVT Goodrive350-19 Series Operation Manual page 323

Goodrive350-19 series VFD for crane
Function
Name
code
Speed-loop output
P23.06
filter
Electromotive slip
compensation
P23.07
coefficient of
vector control
Braking slip
compensation
P23.08
coefficient of
vector control
Current-loop
P23.09 proportional
coefficient P
Current-loop
P23.10 integral coefficient
I
Speed-loop
P23.11
differential gain
High-frequency
P23.12
current-loop
Description
however, if the proportional gain is too large or
integral time is too small, system oscillation and
overshoot may occur; if proportional gain is too
small, stable oscillation or speed offset may
occur.
PI parameters have a close relationship with the
inertia of the system. Adjust PI parameters
depending on different loads to meet various
demands.
P23.00 setting range: 0.0–200.0
P23.01 setting range: 0.000–10.000s
P23.02 setting range:
P23.03 setting range: 0.0–200.0
P23.04 setting range: 0.000–10.000s
P23.05 setting range:
output frequency)
0–8 (corresponding to 0–2
Slip compensation coefficient is used to adjust
the slip frequency of the vector control and
improve the speed control accuracy of the
system. Adjusting the parameter properly can
control the speed steady-state error.
Setting range: 50–200%
The two function codes impact the dynamic
response speed and control accuracy of the
system. Generally, you do not need to modify
the two function codes.
Applicable to SVC mode 0 (P00.00=0), SVC
mode 1 (P00.00=1), and closed-loop vector
control mode (P00.00=3).
Setting range: 0–65535
0–10.00s
In the closed-loop vector control mode
(P00.00=3), when the frequency is lower than
-311-
0.00Hz–P23.05
P23.02–P00.03 (Max.
8
/10ms)
Function parameter list
Default Modify
○
0
○
100%
○
100%
○
1000
○
1000
○
0.00s
○
1000
