INVT Goodrive350-19 Series Operation Manual page 153

Goodrive350-19 series VFD for crane
Function
Name
code
Torque setting
P03.11
method
Torque set
P03.12
through keypad
Torque
P03.13 reference filter
time
Setting source
of forward
rotation
P03.14
upper-limit
frequency in
torque control
1: Keypad (P03.12)
2: AI1 (100% corresponding to triple the motor rated
current)
3: AI2
4: AI3 (same as the above)
5: Pulse frequency HDIA
6: Multi-step torque
7: Modbus communication
8: PROFIBUS/CANopen/DeviceNet communication
9: Ethernet communication (100% corresponding to
triple the motor rated current)
10: Pulse frequency HDIB (100% corresponding to triple
the motor rated current)
11: EtherCAT/Profinet communication
12: Programmable expansion card
13: 216 communication
Note: For setting sources 2–6 and 10, 100%
corresponds to three times the rated motor current.
-300.0%–300.0% (of the motor rated current)
0.000–10.000s
0: Keypad (P03.16)
1: AI1 (100% corresponding to the max. frequency)
2: AI2 (same as the above)
3: AI3 (same as the above)
4: Pulse frequency HDIA (same as the above)
5: Multi-step setting (same as the above)
6: Modbus communication (same as the above)
7: Profibus/CANopen/DeviceNet communication
(same as the above)
8: Ethernet communication (same as the above)
9: Pulse frequency HDIB (same as the above)
10: EtherCAT/Profinet communication
11: Programmable expansion card
12: 216 communication
Note: For setting methods 1–12, 100% corresponds to
-141-
Description
Basic operation guidelines
Default
1
50.0%
0.010s
0
