P25 Group--I/O Card Input Functions - INVT Goodrive350-19 Series Operation Manual

Goodrive350-19 series VFD for crane
Function
Name
code
coefficient
Motor pole pairs in
P24.24 initial pole angle
autotuning
P25 group––I/O card input functions
Function
Name
code
P25.01 Function of S5
P25.02 Function of S6
P25.03 Function of S7
P25.04 Function of S8
P25.05 Function of S9
P25.06 Function of S10
P25.07 Function of S11
P25.08 Function of S12
Expansion card
P25.10 input terminal
polarity
Expansion card
P25.11 virtual terminal
setting
S5 switch-on
P25.14
delay
S5 switch-off
P25.15
delay
S6 switch-on
P25.16
delay
Description
0–128
Description
Same as P05
0x000–0x1FF
BIT7 BIT6
S12 S11
BIT3 BIT2
S8 S7
0x000–0x1FF (0: Disable. 1: Enable)
BIT0: S5 virtual terminal
BIT1: S6 virtual terminal
BIT2: S7 virtual terminal
BIT3: S8 virtual terminal
BIT4: S9 virtual terminal
BIT5: S10 virtual terminal
BIT6: S11 virtual terminal
BIT7: S12 virtual terminal
BIT8: HDI3 virtual terminal
Used to specify the delay time corresponding to
the electrical level changes when the
programmable input terminals switch on or
switch off.
-316-
BIT5 BIT4
S10 S9
BIT1 BIT0
S6 S5
Function parameter list
Default Modify
◎
2
Default Modify
◎
0
◎
0
◎
0
◎
0
◎
0
◎
0
◎
0
◎
0
○
0x000
◎
0x000
○
0.000s
○
0.000s
○
0.000s
