Goodrive350-19 series VFD for crane
Function
Name
code
I/F mode for AM 2 for switching off the output current closed-loop
End frequency for
P04.50 switching off I/F
mode for motor 1
End frequency for
P04.51 switching off I/F
mode for motor 2
Reverse current
P04.52 setting in I/F mode
for AM 1
Reverse current
P04.53 setting in I/F mode
for AM 2
P05 group––Input terminals
Function
Name
code
P05.00 HDI input type
P05.01 Function of S1
P05.02 Function of S2
P05.03 Function of S3
P05.04 Function of S4
P05.05 Function of HDIA
P05.06 Function of HDIB
P05.07 Reserved
Description
control. When the output frequency is lower than
the value of this parameter, the current
closed-loop control in the I/F control mode is
enabled; and when the output frequency is
higher than P04.51, the current closed-loop
control in the I/F control mode is disabled.
Setting range: 0.00–20.00 Hz
P04.44–P00.03
P04.49–P00.03
0.0–200.0%
0.0–200.0%
Description
0x00–0x11
Ones place: HDIA input type
0: HDIA is high-speed pulse input
1: HDIA is digital input
Tens place: HDIB input type
0: HDIB is high-speed pulse input
1: HDIB is digital input
0: No function
1: Run forward
2: Run reversely
3: Three-wire running control
4: Jog forward
5: Jog reversely
6: Coast to stop
-235-
Function parameter list
Default Modify
○
25.00Hz
○
25.00Hz
○
120.0%
○
120.0%
Default Modify
◎
0x00
◎
1
◎
2
◎
7
◎
0
◎
0
◎
0
◎
0
