Goodrive350-19 series VFD for crane
4.4.3 Control circuit wiring of I/O expansion card 2
Expansion terminal
S5
Expansion terminal
S6
Expansion terminal
S7
Expansion terminal
S8
(Externally connected
temperature resistor)
PT1+
PT-
S5
S6
+24V
Goodrive350-19 series expansion card
S5
S6
S7
S8
COM
PW
+24V
PE
PT1+
PT2+
PT-
PE
Figure 4-22 Control circuit wiring of I/O expansion card 2
PT2+
S8
S7
R04A R04C
PW
COM
COM
R03A
Figure 4-23 Terminal layout of I/O expansion card 2
Temperature input
R03C
-36-
Installation guidelines
RO3A
Relay 3 output
RO3C
RO4A
Relay 4 output
RO4C
