INVT Goodrive350-19 Series Operation Manual page 430

Goodrive350-19 series VFD for crane
Function
VFD fault code
VFD identification
code
Running frequency
Set frequency
Bus voltage
Output voltage
Output current
Rotational speed
Output power
Output torque
Closed-loop setting
Closed-loop feedback
Input state
Output state
Analog input 1
Analog input 2
Analog input 3
Analog input 4
Read input of HDIA
high-speed pulse
Read input of HDIB
high-speed pulse
Read the actual step
Address
=10: Communication-based control
Bit7: Reserved
Bit8=0: Speed control =1: Torque control
Bit9=0: Non position control
=1: Position control
Bit10–Bit11: =0: Vector 0
= 3: Space voltage vector
2102H See the description of fault types.
2103H GD350-----0x01A0
3000H 0–Fmax (Unit: 0.01Hz)
3001H 0–Fmax (Unit: 0.01Hz)
3002H 0.0–2000.0V (Unit: 0.1V)
3003H 0–1200V (Unit: 1V)
3004H 0.0–3000.0A (Unit: 0.1A)
3005H 0–65535 (Unit: 1RPM)
3006H -300.0–300.0% (Unit: 0.1%)
3007H -250.0–250.0% (Unit: 0.1%)
3008H -100.0–100.0% (Unit: 0.1%)
3009H -100.0–100.0% (Unit: 0.1%)
000–3F
300AH Corresponding to the local HDIB/
HDIA/S4/S3/S2/S1
000–0F
300BH Corresponding
RO2/RO1/HDO/Y1
300CH 0.00–10.00V (Unit: 0.01V)
300DH 0.00–10.00V (Unit: 0.01V)
300EH -10.00–10.00V (Unit: 0.01V)
300FH
3010H 0.00–50.00kHz (Unit: 0.01Hz)
3011H
3012H 0–15
Data description
=01: Terminal-based control
=1: Vector 1
=2: Closed-loop vector
to local
-418-
Communication protocol
R/W
Compatible
with CHF100A
and CHV100
communication
addresses
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
