P10 Group--Simple Plc And Multi-Step Speed Control - INVT Goodrive350-19 Series Operation Manual

Goodrive350-19 series VFD for crane
Function
Name
code
ACC/DEC time of
P09.15
PID command
PID output filter
P09.16
time
Low frequency
P09.18
integral time
Low frequency
P09.19
differential time
Low frequency
point for PID
P09.20
parameter
switching
High frequency
point for PID
P09.21
parameter
switching
P10 group––Simple PLC and multi-step speed control
Function
Name
code
P10.00 Simple PLC mode
Simple PLC
P10.01
memory selection
P10.02 Multi-step speed 0 Frequency setting range for steps from step 0 to
Running time of
P10.03
step 0
Description
0.0–1000.0s
0.000–10.000s
0.00–10.00s
0.00–10.00s
0–P09.21
P09.20–P00.03
Description
0: Stop after running once. The VFD stops
automatically after running for one cycle, and it
can be started only after receiving the running
command.
1: Keep running in the final value after running
for one cycle. The VFD keeps the running
frequency and direction of the last section after a
single cycle.
2: Cyclic running. The VFD enters the next cycle
after completing one cycle until receiving the
stop command.
0: No power-failure memory
1: Memory after power-off. The PLC memories
its running stage and running frequency before
power-off.
step 15: -100.0–100.0%. 100.0% corresponds to
the max. output frequency P00.03.
-269-
Function parameter list
Default Modify
○
0.0s
○
0.000s
○
0.90s
○
0.00s
○
5.00Hz
○
10.00Hz
Default Modify
○
0
○
0
○
0.0%
○
0.0s (min)
