D.5.3 Recommended cable size
VFD model
GD350-19-1R5G-4-B
GD350-19-2R2G-4-B
GD350-19-004G-4-B
GD350-19-5R5G-4-B
GD350-19-7R5G-4-B
GD350-19-011G-4-B
GD350-19-015G-4-B
GD350-19-018G-4-B
GD350-19-022G-4-B
GD350-19-030G-4-B
GD350-19-037G-4-B
GD350-19-045G-4-B
GD350-19-055G-4-B
GD350-19-075G-4-B
GD350-19-090G-4-B
GD350-19-110G-4-B
GD350-19-132G-4
GD350-19-160G-4
GD350-19-185G-4
GD350-19-200G-4
GD350-19-220G-4
GD350-19-250G-4
GD350-19-280G-4
GD350-19-315G-4
Table D-1 AC 3PH 380V (-15%)–440V(+10%)
Recommended
2
cable size (mm )
RST RST
PE
UVW UVW
2.5 2.5 2.5–6
2.5 2.5 2.5–6
2.5 2.5 2.5–6
2.5 2.5 2.5–6
4 4 2.5–6
6 6 4–10
6 6 4–10
10 10 10–16
16 16 10–16
25 16 25–50
25 16 25–50
35 16 35–70
50 25 35–70
70 35 35–70
95 50 70–120
120 70 70–120
185 95 95–300
240 120 95–300
95*2P 95 95–150
95*2P
95*2P 120
–150*2P
95*2P
150*2P 150
–150*2P
95*4P
95*4P 95*2P
–150*4P
95*4P
95*4P 95*2P
–150*4P
95*4P 95*4P 95*4P
Connectable cable size (mm
P1 PB
(+) (+) (-)
2.5–6 2.5–6
2.5–6 2.5–6
2.5–6 2.5–6
2.5–6 2.5–6
4–6 4–6
4–10 4–10
4–10 4–10
10–16 10–16
10–16 10–16
25–50 25–50
25–50 25–50
35–70 35–70
35–70 35–70
35–70 35–70
70–120 70–120
70–120 70–120
95–300 95–300
95–300 95–300
70–150 70–150
95*2P 95*2P
–150*2P –150*2P
95*2P 95*2P
–150*2P –150*2P
95*4P 95*4P
–150*4P –150*4P
95*4P 95*4P
–150*4P –150*4P
95*4P 95*4P
-491-
Optional peripheral accessories
2
)
Terminal
screw
PE
2.5–6 M4
2.5–6 M4
2.5–6 M4
2.5–6 M4
2.5–6 M4
4–10 M5
4–10 M5
10–16 M5
10–16 M5
16–25 M6
16–25 M6
16–35 M8
16–35 M8
16–35 M8
50–70 M12
50–70 M12
95–240
120–240
35–95
120–240
Nuts are used for
terminals. You are
150–240
recommended to use
a wrench or sleeve.
95*2P
–150*2P
95*2P
–150*2P
95*2P
Fastening
torque
(Nm)
1.2–1.5
1.2–1.5
1.2–1.5
1.2–1.5
1.2–1.5
2.3
2.3
2.3
2.3
2.5
2.5
10
10
10
35
35
